Trituradora móvil tipo rueda K

Trituradora móvil tipo rueda K

La trituradora móvil tipo rueda K es, También conocida como estación trituradora móvil., desarrollado en base a años de experiencia independiente en investigación y fabricación de trituradoras móviles. En combinación con las demandas de los usuarios., La trituradora móvil tipo rueda K está optimizada e innovada en el diseño estructural, equipment configuration and combined application, so as to realize more flexible combinations, greatly widening the application fields and truly realizing the approaching treatment of materials.

Características del producto: Flexible, able to put into production quickly, eco-friendly
  • Tamaño de entrada: 0-930milímetro (for coarse crushing)
  • Capacidad: 0-650HTP (for coarse crushing)
  • Material: Granito, mármol, basalto, caliza, cuarzo, Guijarro, mina de cobre, mineral de hierro

Actuación

72 Machine Models Cover Various Production Demands

K Mobile Crushers own 7 series and 72 machine models, and fully covers various production demands for coarse crushing, intermediate fine crushing, fine crushing, shaping, screening and sand washing. Customer can choose independent operation and combination operation like three-combination, and four-combination, etc.; compared with the other mobile crushers and screens in domestic and foreign markets, this series has more machine types and wider coverage.

Quick Entrance To Operation; Flexibility Saving More Money

Compared with a fixed production line, the K Mobile Crusher has a shorter engineering period and rapider transition, which not only reduces the investment risk and opportunity cost of the investors, but also avoids the demolition and construction after the end of project, making it more economical and environmental. Además, the mobile crusher has excellent value-holding capacity, so that the investor can rapidly invest in a new project, or sell the mobile crusher to get money, thus reducing the investment cost.

General Structure Making Further Upgrading Possible

SBM’s K Mobile Crusher takes the concept of modularization. The general structural layout can realize the direct replacement of main parts without replacing the body, so as to satisfy the crushing and screening demands at different stages; if the user needs to expand the production capacity, replacing the main parts can accomplish the upgrading of mobile crusher and save reinvestment cost of the body. Además, the wheel-type mobile crusher can move in remote and rugged areas, greatly reducing the road construction cost in earlier stage.

Hydraulic Centralized Control Makes Operation & Maintenance Simpler

All actions are controlled by intensified hydraulic system so that the operator can simply and rapidly set the operating actions of the mobile crusher; in consideration that the widely used hydraulic control devices will require certain machine maintenance, SBM adopted centralized lubrication mode, and the operator can rapidly complete the maintenance on the road directly. Por lo tanto, the operation and maintenance management will greatly save the labor cost.

Procesamiento Digitalizado, Mayor precisión

Hay decenas de líneas de máquinas herramienta de control numérico.. Operaciones como planchas de acero’ corte, doblando, cepillado, el fresado y la pulverización de pintura se controlan numéricamente. La precisión de mecanizado es alta., especialmente para las partes centrales.

Suministro suficiente de piezas de repuesto, Operación sin preocupaciones

SBM, cuyos negocios cubren la producción y las ventas, asume la responsabilidad de cada máquina producida por nosotros mismos. Podemos ofrecer a los clientes servicios técnicos sobre productos y repuestos originales para garantizar un funcionamiento sin preocupaciones..

Principio de funcionamiento

A K Wheel-type Mobile Crusher is composed of the frame assembly, automobile components, hosts & accessory equipment, power system and hydraulic electronic control system. When moving, the mobile crusher is hooked on a trailer and then move by virtue of its wheels. During installation, with the external power, the hydraulic cylinder can get controlled by the electronic control system to finish equipment installation. Durante la operación, with external power, motors of hosts and accessories work to drive the equipment to work. Generalmente, materials are sent from the hopper or by belt conveyors to the hosts for crushing and screening. After being processed, finished products are transported by belt conveyors, también.

Parametros del producto

Coarse crushing portable plant

Modelo Screening equipment Crushing equipment Main belt conveyor Hopper volume () Max.feeding size (milímetro) Transportation dimension (milímetro)
KE600-1 TSW0936 PE600×900 B800×8.3m 5.3 500 12150×2600×3950
KE750-1 TSW1139 PE750×1060 B1000×8.5m 7 630 13000×2850×4400
KE760-1 TSW1139 PEW760 B1000×8.5m 7 640 13000×2800×4200
KE860-1 TSW1345 PEW860 B1200×9.5m 8 720 14600×3000×4500
KE1100-1 TSW1548 PEW1100 B1400×9.5m 11 930 14050×2900×4000
KJ98-1 TSW1139 HJ98 B800×8.3m 5.9 560 12150×2600×3950
KJ110-1 TSW1345 HJ110 B1000×8.5m 8.5 660 13200×3000×4400
KJ125-1 TSW1345 HJ125 B1400×9.5m 8 800 14600×3000×4500
KF1214Ⅱ-1 TSW0936 PFW1214Ⅱ B800×8.3m 5.3 500 12150×2600×3980
KF1315Ⅱ-1 TSW1345 PFW1315Ⅱ B1200×9.5m 8 600 14600×3100×4500
KF1415Ⅱ-1 TSW1548 PFW1415Ⅱ B1200×9.5m 11 700 14050×3000×4000

Medium and fine crushing and screening portable plant

Modelo Screening equipment Crushing equipment Belt conveyor below screen Max.feeding size (milímetro) Transportation dimension (milímetro)
KC75-2 3Y1848 CS75B B800×7.5m 150 12600×3000×4500
KC160-2 3Y1860 CS160B B800×8.5m 205 13800×3000×4500
KT100-2 3Y1848 HST100H1 B800×7.5m 135 12600×3000×4500
KT160-2 3Y1860 HST160H1 B800×8.5m 185 13800×3000×4500
KT250-2 3Y1860 HST250H1 B800×8.5m 215 13800×3000×4500
KH300-2 3Y1860 HPT300C2 B800×8.5m 210 13800×3000×4500
KF1214-2 3Y1860 PFW1214Ⅲ B800×8.5m 250 13800×3000×4500
KF1315-2 3Y2160 PFW1315Ⅲ B1000×8.5m 300 13800×3150×4500
KF1318-2 3Y2160 PFW1318Ⅲ B1000×8.5m 300 13800×3150×4500
KS1848-1 3Y1848 —— B800×7.5m —— 12590×3000×4500
KS1860-1 3Y1860 —— B800×8.5m —— 13800×3000×4500
KS2160-1 3Y2160 —— B1000×8.5m —— 13800×3150×4200

Complete portable plant

Modelo Screening equipment Crushing equipment Belt conveyor below screen Hopper volume () Max.feeding size (milímetro) Transportation dimension (milímetro)
KC75-2D 3Y1848 CS75B B800×7.5m 7.2 150 16850×3000×4500
KC160-2D 3Y1860 CS160B B800×8.5m 7.2 205 16850×3000×4500
KT100-2D 3Y1848 HST100H1 B800×7.5m 7.2 135 16850×3000×4500
KT160-2D 3Y1860 HST160H1 B800×8.5m 7.2 185 16850×3000×4500
KT250-2D 3Y1860 HST250H1 B800×8.5m 8 215 16850×3000×4500
KH300-2D 3Y1860 HPT300C2 B800×8.5m 8 210 16850×3000×4500
KF1214-2D 3Y1860 PFW1214Ⅲ B800×8.5m 7.2 250 16120×3000×4500
KF1315-2D 3Y2160 PFW1315Ⅲ B1000×8.5m 8 300 16120×3150×4500
KF1318-2D 3Y2160 PFW1318Ⅲ B1000×8.5m 8 300 16120×3150×4500
KS1848-1D 3Y1848 —— B800×7.5m 7.2 —— 16910×3000×4500
KS1860-1D 3Y1860 —— B800×8.5m 7.2 —— 16910×3000×4500
KS2160-1D 3Y2160 —— B1000×8.5m 8 —— 16910×3150×4500

Sand-making and shaping portable plant

Modelo Screening equipment Crushing equipment Belt conveyor below screen Max.feeding size (milímetro) Transportation dimension (milímetro)
KV8518-2 3Y1848 VSI8518 B800×7.5m 40 14200×3000×4500
KV8522-2 3Y1860 VSI5X8522 B800×8.5m 40 14200×3000×4500
KV9526-2 3Y1860 VSI9526 B800×8.5m 45 14200×3000×4500
KV9532-2 3Y1860 VSI5X9532 B800×8.5m 45 14200×3000×4500

Fine crushing and sand washing portable plant

Modelo Screening equipment Sand washing machine Crushing equipment Max.feeding size (milímetro) Transportation dimension (milímetro)
KV8518-2X 3Y1848 XL-915 VSI8518 40 13700×2950×4500
KV8522-2X 3Y1860 2XL-915 VSI5X8522 40 13700×3000×4500
KV9526-2X 3Y1860 2XL-915 VSI9526 45 13700×3000×4500
KV9532-2X 3Y1860 2XL-915 VSI5X9532 45 13700×3000×4500
KC75-2X 3Y1848 XL-915 CS75B 150 13700×3000×4500
KC160-2X 3Y1860 XL-915 CS160B 205 13700×3000×4500
KH300-2X 3Y1860 2XL-915 HPT300C2 210 13700×3000×4500
KT250-2X 3Y1860 2XL-915 HST250H1 215 13700×3000×4500

Three-in-one portable plant

Modelo Screening equipment Feeding equipment Crushing equipment Hopper volume () Max.feeding size (milímetro) Transportation dimension (milímetro)
KF1214-3 3Y1848 TSW0936 PF1214 5.5 300 16400×2810×4500
KF1214Ⅱ-3 3Y1848 TSW0936 PFW1214Ⅱ 5.5 500 16400×2810×4500
KE500-3 3Y1548 TSW0936 PE500×750 5.5 425 16400×2760×4500
KE600-3 3Y1848 TSW0936 PE600×900 5.5 500 16400×2760×4500

Four-in-one portable plant

Modelo Screening equipment Feeding equipment Coarse crushing equipment Medium crushing equipment Max.feeding size (milímetro) Transportation dimension (milímetro)
KE400C55-4 3Y1237 GZD960×3500 PE400×600 PYB900 350 15150×2800×4500
KE400C75-4 3Y1237 GZD960×3500 PE400×600 CS75B 350 15150×2800×4500
KE500C55-4 3Y1237 GZD960×3500 PE500×750 PYB900 425 15150×2800×4500
KE500C75-4 3Y1237 GZD960×3500 PE500×750 CS75B 425 15150×2800×4500
KE400F110-4 3Y1237 GZD960×3500 PE400×600 PF1010 350 15150×2800×4500
KE500F110-4 3Y1237 GZD960×3500 PE500×750 PF1010 425 15150×2800×4500

Nota:

Imágenes del producto y parámetros sobre los modelos., datos, las actuaciones y especificaciones en este sitio web son solo para referencia. Existe la posibilidad de que SBM realice cambios en la información mencionada anteriormente. Para mensajes específicos, Consulta los objetos reales y los manuales de usuario.. Sin instrucciones especiales, SBM se reserva el derecho de explicar todos los datos involucrados en este sitio web.
